**Currently en route to our facility. It will take about 30 days to arrive, after which we will test and certify it.**
Manufactured in 2014
Included Items
- Leica CM1950 Cryostat
- Anti-Roll Plate
- Blade Holder
- Power Cable
Certified to Perform at Manufacturer Specifications
After your instrument arrives at our facility, it will be inspected and tested to certify it performs at manufacturer specifications. If any component does not pass testing, then it will receive the service necessary to restore full functionality.
Specifications
|
Manufacturer
|
Leica
|
|
Model
|
CM1950
|
|
Electrical Specifications
|
120V, 60Hz, 1300VA
|
|
Dimensions (W x D x H)
|
33 x 33 x 48 in.
|
|
Microtome
|
|
Type
|
Rotary microtome, encapsulated
|
|
Section thickness range
|
1 to 100 um
|
|
Trimming range
|
Clinic: 10 - 40 um
Research: 1 - 600 um
|
|
Total specimen feed
|
25 mm + 1 mm
|
|
Vertical stroke
|
59 mm +/- 0.5 mm
|
|
Specimen retraction
|
20um (can be deactivated)
|
|
Maximum specimen size
|
50 x 80 mm
|
|
Cutting speed
|
Slow: 0-50 strokes/min
Fast: 0-85 strokes/min
Vmax: 85-90 strokes/min
|
|
Specimen orientation
|
8° (x, y-axis)
|
|
Electric coarse feed
|
Slow: 300 um/s
Fast: 900 um/s
|
|
General Information
|
|
Operating temperature range
|
18°C to 35°C
|
|
Temperature range during storage
|
+5°C to +55°C
|
|
Relative humidity
|
max. 60% non-condensing
|
|
Storage humidity
|
<60%
|
|
Refrigeration System (60Hz)
|
|
Temperature range
|
0°C to -35°C +/-5 K, adjustable in 1 K increments at ambient temperature of 20°C
|
|
Cooling time to -25°C
|
approx. 5 hours
|
|
Cooling time to -35°C
|
approx. 8 hours
|
|
Refrigeration capacity
|
690 W
|
|
Cut-out pressure
|
25 bar
|
|
Safety factor
|
3
|
