UltraGenizer Ultra High Pressure Homogenizer

Specs Below
click to see what's included
UltraGenizer High Shear Homogenizer:

UltraGenizer is a laboratory ultra high pressure processing device. It is an electrically-driven and bench-top high shear homogenizer, which requires no compressed air or hydraulic oil to achieve maximum 4,200 bar (60,000 psi) operating pressure.





Performance Highlight
  • Energy efficient: 1/2 energy loss of the most homogenizers
  • Small: Integrated design deliver the lightweight and small dimensions
  • Smart: Programming control systems confer diligent and foolproof functions: controlled inlet volume ± 0.1mL; auto stop with time/volume
  • Silent: Noiseless performance
  • Strong: More than 150 mL/min at 60,000 psi
  • CE compliant and RoHs compliant



Application
  • Nano emulsions
  • Nano dispersions
  • Liposomes
  • Nanoparticles
  • Graphene
  • Deagglomeration





Specifications:

Catalog No. UG-20K UG-25K UG-30K UG-40K UG-45K UG-60K

Flow Rate

35L/hr 30L/hr 25L/hr 20L/hr 15L/hr 12L/hr
Min. Sample 30mL 25mL 25mL 20mL 20mL 15mL
Max. Pressure 20,000psi 25,000psi 30,000psi 40,000psi 45,000psi 60,000psi
Dimensions(cm) 150 x 68 x 48



Weight(kg) ~260kg (573lbs)



Max. Temp. 70ºC (158ºF)



Power 380V



Cleaning Flush to clean



Application Nano emulsion, fat emulsion, liposome, cell disruption, nano dispersion, de-agglomeration, nanoparticle, graphene



Features Digital display of pressure or pressure gauge





Standard Features:

Parts

Ultra Y-type diamond interaction chamber with cooling option

Control System High pressure programming control systems: touch screen, speed control, auto stop control by volume, time, pressure or temperature, settable volume control as low as 1mL, display of flow rate and time, overload protection
Pressure Gauge Digital display on the touch screen
Inlet Type 3/8" HP coupling
Outlet Type 3/8" HP coupling
Inlet Reservoir 100mL syringe
Outlet Reservoir 100mL syringe
Product Material 316L stainless steel, tungsten carbide, viton, teflon
Material Standard Sanitary grade, FDA, GMP
Warranty 1 year against any manufacturing defects





Option Features:

Parts High pressure extruders, homogenizing valves, heat exchanger
Control System Mechanical control: speed, start, stop control
Detector Pressure gauge, pressure transducer up to 8 optional, temperature transducer up to 8 optional
Outlet Type Tri-clamp or luer
Heat Exchanger HPE-100-3D; HPE-150-3D; HPE-200-3D
Liposome Extruder GOE-200mL; GOE-1000mL
Inlet Reservoir 10mL, 20mL, 50mL, 100mL, 200mL, 500mL syringes, S/S cylinder, jacketed glass cylinder or online
Outlet Reservoir 10mL, 20mL, 50mL, 100mL, 200mL, 500mL syringe, S/S cylinder, jacketed glass cylinder or online
Cylinder Titanium high pressure cylinder (resistant to strong acid and base)
