- Distek Evolution 6100 Bathless Dissolution Test System
- Calibration Probe
- x6 1 Liter Dissolution Vessels
- x6 Paddles
- x6 Heating Jackets
- Power Cable
- 90-Day Warranty
After its initial disinfection and inspection, our technicians tested the Distek Evolution 6100 bathless dissolution system with the following results:
- User interface navigation: PASSED
- Lower and raise paddles: PASSED
- Paddle rotation for several hours: PASSED
- Vessel heating jackets: PASSED
Notice: This dissolution apparatus has some minor cosmetic blemishes. Please review the available photos to see the physical condition before purchasing.
|
Manufacturer
|
Distek
|
|
Model
|
Evolution 6100
|
|
Serial No.
|
6101445
|
|
Dissolution vessels
|
Six standard/Up to seven vessels
|
|
Volume
|
500mL - 1000mL programmable
|
|
Vessel heating rate
|
Approx. 1.5°C per minute
|
|
RPM control range
|
25-300 rpm, digitally controlled, closed loop
|
|
Resolution
|
0.1 rpm
|
|
Accuracy
|
+/-0.2 rpm
|
|
Display
|
LED's, .75" (19mm) high
|
|
Motor
|
High torque, permanent magnet
|
|
Vessel temperature control
|
Independently controlled two-zone heater jackets
|
|
Display resolution
|
0.01°C
|
|
Accuracy
|
+/-0.25°C
|
|
Calibration
|
Built-in calibration probe
|
|
Shaft wobble
|
Less than 0.010" (0.254mm) total indicator runout
|
|
Program modes
|
Manual (Individual vessel control), Automatic (Up to 100 pre-programmed methods), External (produKEY Memory Device)
|
|
Interface ports
|
RS-232 (2), RS-485 (1), Parallel printer (1)
|
|
Power rating
|
115V~, 50/60Hz, 15A
|
|
Dimensions (W x D x H)
|
26 x 20 x 39 in
|
|
Weight
|
150 lb
|
